3M™ Scotchcast™ 5230N Electrical Epoxy Resin 5lb

SKU
TMEP00001
3M Scotchcast 5230n 5lb
£0.00 £0.00

3M™ Scotchcast™ 5230N is a one part, general purpose epoxy powder resin that is blue pigmented. It is a rapid heat curing product that has been designed to give a tough and moisture resistant coating to many substrates.

Scotchcast™ 5230N has been specially formulated for use in electrostatic electrostatic fluid bed process and has excellent heat, chemical and moisture resistance

Product Benefits

  • Specially formulated for use in electrostatic fluid bed process
  • Excellent electrical properties
  • Excellent heat, chemical and moisture resistance
  • Superior cut-through resistance
  • Technical Properties

  • Colour: Blue
  • Abrasion Resistance: .08 grams loss Specific Gravity (cured): 1.60
  • Dielectrical Strength: 12 - 15 mil /30 μm to 375 μm coating - 1000 v/mil (39 v/micron)
  • Abrasion Resistance: .11 grams loss
  • Thermal Shock: 10 cycles - 75°C to 155°C 12 - 15 mil /30 μm to 375 μm coating 1/8” sandblasted steel - PASSES
  • Thermal Conductivity: 0.30 w/mk

Product Specifications

  • UL 1446 electrical insulation systems approval at Class-155(F)
